Arbitrary fixed length, step length double-sided printing with photoelectric tracking, ensuring accuracy and stability, and automatic shutdown in case of label missing.
The equipment discharges in a one-out-one mode, with automatic counting and alarm function that can be set to any number.
Full-automatic computer synchronous release film glue breaking control system, and automatic shutdown system when there is no release film. It is a patented technology (high-speed and stable, clean and tidy glue breaking).
|
MODEL |
DX-900 |
|
Width range |
Max 1000mm |
|
Length range |
Max 800mm |
|
Max. Spend |
~150/min |
|
Suitable bag |
Express bag |
|
Total power |
~ 7kw（ Actual load approx. 60 ~70%） |
|
Voltage |
Three-phase 220V.Uniphase 220V.Frequency 50-60HZ. |
|
L x W x H Machine dimension |
3500x 1500 x 2100mm |
|
Rack material |
8-10Channel |
|
Equipment weight |
900Kg |
|
Main motor |
Power: 1.5Kw |
|
Feeding part |
|
|
Feeding motor |
Direct current |
|
Stepmotor |
Auto control |
|
Motor origin |
China.Shanghai |
|
Electrical parts |
|
|
frequency changer/inverter |
Defu |
|
Motor switch |
Zhejiang Chint |
|
Computer assembly |
Xuncheng |
|
Electrostatic rod |
16KV |
|
Power distribution cabinet motor |
Circulating air cooling |
|
Gluing machine |
With glue breaking function |
How can the production efficiency of bag-making machines be improved?
Select appropriate materials, set machine parameters reasonably, maintain equipment cleanliness, perform regular maintenance, and ensure operators are proficient in machine operation to effectively enhance production efficiency.
How should bag-making machines be maintained and serviced?
Regularly inspect and clean the machine, ensure proper lubrication of moving parts, replace wear-prone components (such as blades and seals) on a regular basis, and inspect the electrical system to ensure stable operation.
How long does it take to calibrate a bag-making machine?
Calibration time typically ranges from a few hours to one day, depending on the machine model and production requirements. Equipment setup and operator proficiency also affect calibration speed.
What is the production efficiency of a bag-making machine?
The production efficiency of a bag-making machine varies by model, typically reaching hundreds to thousands of bags per minute. Specific efficiency depends on the material used and the type of bag.
What materials are suitable for bag-making machines?
Bag-making machines are suitable for a variety of plastic film materials, such as polyethylene (PE), polypropylene (PP), composite materials, etc., and are widely used in fields such as food packaging and daily necessities packaging.
