High Speed Vest Bag Making Machine

This machine uses HDPE and LDPE tubular films as raw materials to produce printed, plain, and vest bags. It adopts new computer control, dual servo motors for length positioning, and a liquid crystal touch screen for real-time display.

Bag making width
50-500mm
Bag making length
30-1000mm
Bag making precision
±0.2mm
Production speed
30-240pcs/min

GET IN TOUCH NOW

Downloads

Video

Product Parameters

Model	DX-600	DX-800	DX-1000
Production speed	30-240pcs/min	30-220pcs/min	30-220pcs/min
Bag width	50-500mm	50-700mm	50-900mm
Bag length	30-1000mm	30-1000mm	30-1000mm
Bag making precision	±0.2mm	±0.2mm	±0.2mm
Total power	8kw	8kw	10kw
Overall dimension	33009501600mm	330010501600mm	33011501600mm
Machine weight	1000kg	1100kg	1200kg

Product Features

Fully computer-controlled throughout the process, enabling adjustment of bag length and production speed.
Components have self-detection functions.
Automatic film supply and adjustment, no need to adjust tension. The machine stops automatically when the film is used up, when film supply is blocked, or when bags get stuck.
Stops automatically in case of color scanning failure, ensuring high efficiency and productivity, thus saving labor and time.
High-speed and efficient, suitable for processing tubular plastic plain and color-printed bound vest bags (vest bags).
Adopts advanced photoelectric eye tracking to ensure precise printing pattern positioning. Synchronized sealing and heat cutting without tension, with firm and beautiful bottom sealing.
Equipped with multiple automatic protection functions such as energy-saving, overload, overvoltage, and overcurrent.
Comes with an automatic counting device, which can set the number of bound sheets arbitrarily. After stacking to the set number, it automatically discharges and resets.

Product Details

upload/1c/202508/vest-bag-making-machine.jpg

Feeder Part

upload/1c/202508/vest-bag-making-machine-2.jpg

Film Bonding by Heat

upload/1c/202508/vest-bag-making-machine-3.jpg

Magnetic Powder Brake

FAQ

Find here Q&A related to High Speed Vest Bag Making Machine customization, service, quality.

GET IN TOUCH

How can the production efficiency of bag-making machines be improved?

Select appropriate materials, set machine parameters reasonably, maintain equipment cleanliness, perform regular maintenance, and ensure operators are proficient in machine operation to effectively enhance production efficiency.

How should bag-making machines be maintained and serviced?

Regularly inspect and clean the machine, ensure proper lubrication of moving parts, replace wear-prone components (such as blades and seals) on a regular basis, and inspect the electrical system to ensure stable operation.

How long does it take to calibrate a bag-making machine?

Calibration time typically ranges from a few hours to one day, depending on the machine model and production requirements. Equipment setup and operator proficiency also affect calibration speed.

What is the production efficiency of a bag-making machine?

The production efficiency of a bag-making machine varies by model, typically reaching hundreds to thousands of bags per minute. Specific efficiency depends on the material used and the type of bag.

What materials are suitable for bag-making machines?

Bag-making machines are suitable for a variety of plastic film materials, such as polyethylene (PE), polypropylene (PP), composite materials, etc., and are widely used in fields such as food packaging and daily necessities packaging.
